COMWAY CS-06 Professional Thermal Fiber Hot Stripping Clamp is the upgraded multi-core optical fiber thermal stripping tool, replacing traditional single-fiber manual stripping to greatly improve field FTTH, data center, fiber fusion splicing construction efficiency. As a professional hot stripping clamp, it is designed to meet the high-precision requirements of fiber optic engineering, making it an essential tool for fiber optic engineers.
Adopt horizontal widened heating stripping slot design, low pulling force operation, clean and complete coating removal without scratching bare fiber cladding. This thermal fiber stripper is compatible with 125μm cladding fiber, 200–400μm coating diameter, supports single-core pigtail, multi-core bundle fiber, ribbon fiber, invisible fiber batch stripping, maximum stripping length up to 30mm—perfect for multi-scene fiber processing needs.
Equipped with 4 adjustable temperature gears (80/90/100/120℃), Standard & Eco dual power modes. This rechargeable optical fiber stripping tool features fast 4s heating response, LED light & sound prompt for heating completion, ensuring efficient operation. Built-in 7.4V 2000mAh large-capacity rechargeable lithium battery, Eco mode supports about 400 continuous stripping cycles; USB Type-C universal charging, compatible with power bank, adapter for outdoor mobile operation, solving the trouble of field power supply.
Ergonomic lightweight portable body (365g), durable metal heating fixture, automatic power-off protection & countdown reminder, safe and stable long-time field work. The horizontal heating fiber clamp is widely used in fiber optic splicing maintenance, FTTH network laying, optical cable engineering, laboratory fiber processing scenarios, covering all fiber stripping needs with stable performance and long service life.
Core Product Features
-
Multi-fiber compatible: Bare fiber 1–36 cores, ribbon fiber 2–12 cores, bundle fiber 1–36 cores, pigtail & invisible fiber—meets diverse thermal stripping needs
-
4-grade precise temperature adjustment (80/90/100/120℃), adapts different fiber coating materials for clean stripping
-
Ultra-fast 4s heating, LED & audible prompt for ready status—improves work efficiency of the hot stripping clamp
-
Standard/Eco dual modes, long battery endurance, ≥400 times stripping per full charge—ideal for outdoor use
-
USB-C reversible charging, support outdoor power bank supply—convenient for field FTTH splicing work
-
Low-resistance hot stripping, no damage to 125μm bare fiber, smooth & clean stripping surface—meets high-precision fusion splicing requirements
-
Compact ergonomic design, portable anti-drop, suitable for field & lab dual use—practical for fiber optic engineers
-
Automatic shutdown & overheat protection, safe and reliable operation—ensures long-term use of the thermal fiber stripper
Technical Specifications
|
Parameter
|
Details
|
|---|---|
|
Model
|
COMWAY CS-06
|
|
Applicable Fiber
|
Bare fiber, ribbon fiber, bundle fiber, pigtail, invisible fiber
|
|
Fiber Cladding
|
125μm
|
|
Coating Diameter
|
200–400μm
|
|
Max Stripping Length
|
30mm
|
|
Temperature Range
|
80℃ / 90℃ / 100℃ / 120℃
|
|
Heating Time
|
4 seconds (Eco mode)
|
|
Working Modes
|
Standard Mode + Power Saving Eco Mode
|
|
Battery
|
7.4V 2000mAh Rechargeable Li-ion
|
|
Charging Interface
|
USB Type-C (5V/3A, 9V/2A, 12V/1.5A)
|
|
Stripping Cycles (Full Charge)
|
~400 times (Eco mode)
|
|
Size
|
123×48×32mm
|
|
Net Weight
|
365g
|
Package Included
1 × COMWAY CS-06 Thermal Hot Stripping Clamp
1 × USB Charging Cable
1 × Portable Storage Case
1 × English User Manual
1 × USB Charging Cable
1 × Portable Storage Case
1 × English User Manual
FAQ
Q1: Which fiber types can COMWAY CS-06 thermal fiber stripper strip?
A: The COMWAY CS-06 hot stripping clamp applies to 125μm bare fiber, 200–400μm coated fiber, single pigtail, 1–12 cores ribbon fiber, 1–36 cores bundle fiber and invisible optical fiber, meeting diverse fiber processing needs.
Q2: How long does COMWAY CS-06 take to heat up and how many strips per charge?
A: The CS-06 thermal fiber stripper only takes 4 seconds to reach working temperature. A fully charged battery can finish about 400 stripping operations in Eco power-saving mode, suitable for long-time field work.
Q3: Is COMWAY CS-06 hot stripping clamp suitable for outdoor field construction?
A: Yes. The COMWAY CS-06 thermal fiber stripper adopts USB Type-C charging, supports power bank supply, is lightweight and portable, with automatic temperature control & safety protection, fully meeting outdoor FTTH and fiber splicing field work requirements.
Q4: Will COMWAY CS-06 hot stripping damage the bare optical fiber?
A: The CS-06 hot stripping clamp adopts constant temperature hot soft stripping technology, low pulling force operation, no scratch or damage to 125μm cladding, keeping the fiber surface smooth and meeting high-precision fusion splicing requirements.
Q5: Does COMWAY CS-06 have temperature adjustment function?
A: Yes. The COMWAY CS-06 thermal fiber stripper has 4 gears adjustable temperature (80/90/100/120℃), which can match different fiber coating materials, with Standard & Eco dual working modes optional.
Q6: How to charge the COMWAY CS-06 thermal stripper?
A: The CS-06 hot stripping clamp uses a standard USB-C cable, which can be charged with an adapter, power bank, or computer USB port, universal and convenient for outdoor and indoor use.
